2015 Volvo V60 generation Y20 Facelift D5 Plug-in Hybrid AWD Geartronic, 6-speed
- Plug-in Hybrid Diesel
- Sweden
Photos
Specifications
Vehicle Details
- Year
- 2015
- Make
- Volvo
- Model
- V60
- Variation
- generation Y20 Facelift D5 Plug-in Hybrid AWD Geartronic, 6-speed
- Seats
- 5
- Doors
- 5
- Fuel
- Plug-in Hybrid Diesel
- Drivetrain
- AWD
Powertrain
- Engine Name
- 2.4 11.20 kWh I5
- Engine Configuration
- Inline
- Power (hp)
- 231 hp
- Power (kW)
- 170 kW
- Brake Horsepower
- 228 bhp
- Torque (Nm)
- 400 Nm
- Torque (lb-ft)
- 295 lb-ft
- RPM at Max Power
- 4,000 rpm
- RPM at Max Torque
- 1,500 rpm
- Displacement (cc)
- 2,400 cc
- Displacement (litres)
- 2.4 l
- Cylinders
- 5
- Valves Per Cylinder
- 4
- Bore
- 81 mm
- Stroke
- 93.15 mm
Performance & Efficiency
- Top Speed (km/h)
- 210 km/h
- Top Speed (mph)
- 130 mph
- Acceleration, 0-100 km/h
- 6.9 s
- Combined Consumption
- 1.8 L/100 km
Dimensions & Weight
- Length
- 4,635 mm
- Width
- 28 mm
- Width With Mirrors
- 2,097 mm
- Height
- 1,484 mm
- Wheelbase
- 2,776 mm
- Track, Front
- 1,588 mm
- Track, Rear
- 1,585 mm
- Ground Clearance
- 136 mm
- Curb Weight
- 2,048 kg
- Gross Weight
- 2,505 kg
- Cargo Capacity
- 625 kg
- Max Roof Load
- 90 kg
Interior Dimensions
- Head Room, Front
- 999 mm
- Head Room, Rear
- 954 mm
- Leg Room, Front
- 1,064 mm
- Leg Room, Rear
- 850 mm
- Shoulder Room, Front
- 1,447 mm
- Shoulder Room, Rear
- 1,402 mm
Chassis & Body
- Front Doors
- Conventional
- Door Handles
- Swing-out
- Mirror Type
- Conventional
- Window Lifts, Front
- Powered
- Heated Windows
- Rear
- Heat-Insulating Windows
- First Row, Front, Rear, Second Row
- Antenna
- Shark Fin
Brakes & Wheels
- Front Brakes
- Disc Brakes
- Rear Brakes
- Disc Brakes
- Tire Pressure Monitoring System
- Yes
- Number of Bolts
- 5
- Bolt Distance
- 108
- Nut/Bolt Dimensions
- M14x1.5
- Central Bore, Front
- 63.4
- Fastening Type
- Lug Bolts
- Tightening Torque
- 140 Nm
- Rim Material
- Alloy
- Rim Type
- Disc Wheel
Lighting
- Low Beam
- H7
- Main Beam
- H9
- Rear Lights
- Halogen
- Daytime Running Light
- LED
- Fog Lights
- Yes
Fuel & Engine Details
- Tank Volume
- 45 l
- Compression Ratio
- 16.5 :1
Electric
- Electric Vehicle Type
- Plug-in Hybrid
- Battery Capacity
- 11.2 kWh
- Electric Range (km)
- 50 km
- Electric Range (mi)
- 18 mi
Suspension & Exterior
- Cooling
- Ventilated
- Independent
- Yes
- Spring, Rear
- Coil
- Adjustments
- Electrical
- Heated
- Yes
- Turning Signal
- Yes
- Rear
- Yes
- Headlight Range Adjustment
- Manual
Instruments & Infotainment
- Trip Computer
- Yes
- Speedometer
- Digital
- Tachometer
- Digital
- Fuel Gauge
- Digital
- Coolant Temperature
- Digital
- Climate Control
- Automatic
- Number of Climate Zones
- 2
- Air Condition
- Yes
- Pollen Filter
- Yes
- Outside Temperature Indicator
- Yes
- Radio
- AM, FM
- Bluetooth
- Optional
- Center Display
- 5 - 7"
- Center Display Controls
- Buttons, Rotary Dial
- Total Number of Speakers
- 6 - 12 pcs
- Adjustments
- Telescope, Tilt
Interior & Controls
- Cup Holders
- Yes
- Read Light
- Front, Rear
- Guide Light
- Yes
- Make-up Mirror
- Driver Side, Passenger Side
- Clock
- Yes
- 12V Outlet
- Front
- Carpets
- Yes
- Multifunction Steering Wheel
- Yes
- Cruise Control
- Activate/Deactivate, Speed Up/Down (Buttons)
- Heated
- Optional
- Power Steering
- Yes
- Number of Spokes
- 3
- Material
- Leather
- Colour
- Black
- Steering Mechanism
- Rack and Pinion
- Rear Trunk
- Yes
- Volume
- 430 l
- Hatch Opening Type
- From Roof
- Transmission Knob Material
- Leather
Seats
- Power Seat, Driver
- Optional
- Power Seat, Passenger
- Optional
- Heated Seats
- Optional
- Armrest
- Middle
- Type of Seat
- Adult
- Collapsible
- Manual
Convenience & Equipment
- Keyless Entry
- Optional
- Cruise Control
- Yes
- Cameras
- Optional
- Voice Control
- Optional
- GPS
- Optional
- Driving Mode Selection
- Optional
- Horn
- Dual Note
- Tire Repair Kit
- Yes
- Compressor
- Yes
- Fire Extinguisher
- Optional
- Warning Triangle
- Yes
- First Aid Kit
- Yes
Seatbelts
- Height Adjustable Retractor
- Yes
- Manual
- Yes
- Three-Point-Belt
- Centre Rear Seat, Front Seats, Outer Rear Seats
Safety & Driver Assistance
- Electronic Stability Control (ESC)
- Yes
- Forward Collision Warning (FCW)
- Optional
- Lane Assist System
- Optional
- Sign Assist
- Optional
- Autonomous Emergency Brake System (AEB)
- Yes
- City
- Yes
- Anti-lock Braking System (ABS)
- Yes
- Electronic Brakeforce Distribution (EBD)
- Yes
- Electronic Brake Assist (BA/EBA)
- Yes
- Differential Lock
- Electronic
- Parking Sensors
- Optional
- Blind Spot Detection (BLIS)
- Optional
- Rain Sensors
- Yes
- Immobiliser
- Yes
Security
- Anti-theft Alarm
- Optional
- Central Locking
- Remote
Airbags & Restraints
- Frontal Airbag
- Driver: Yes, Passenger: Yes, Rear: -
- Side Chest Airbag
- Driver: Yes, Passenger: Yes, Rear: -
- Side Head Airbag
- Driver: Yes, Passenger: Yes, Rear: -
- Airbag cut-off Switch
- Driver: -, Passenger: Optional, Rear: -
- Seat Belt Reminder
- Driver: Yes, Passenger: Yes, Rear: -
- Belt Pretensioner
- Driver: Yes, Passenger: Yes, Rear: Yes
- Belt Load Limiter
- Driver: Yes, Passenger: Yes, Rear: Yes
Classification
- Australian Classification
- Medium Car
- European Segment
- D-Segment
Quick Facts
- Fuel Type
- Plug-in Hybrid Diesel
- Country
- Sweden
