2016 Cadillac ATS (EU) ATS-V Coupé (EU) Hydra-Matic, 8-speed

  • Gasoline
  • United States
8.9

12 Reviews

Cadillac
United States

United States

470hp

Power

1st Generation Facelift

Generation

Photos

Specifications

Vehicle Details

Year
2016
Make
Cadillac
Model
ATS (EU)
Variation
ATS-V Coupé (EU) Hydra-Matic, 8-speed
Generation
1st Generation Facelift (2015-2019)
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
RWD

Powertrain

Engine Name
3.6 V6
Engine Configuration
V
Power (hp)
470 hp
Power (kW)
346 kW
Brake Horsepower
464 bhp
Torque (Nm)
603 Nm
Torque (lb-ft)
445 lb-ft
RPM at Max Power
5,850 rpm
RPM at Max Torque
3,500 rpm
Displacement (cc)
3,564 cc
Displacement (litres)
3.6 l
Cylinders
6
Valves Per Cylinder
4
Bore
94 mm
Stroke
85.6 mm

Performance & Efficiency

Top Speed (km/h)
304 km/h
Top Speed (mph)
189 mph
Acceleration, 0-100 km/h
3.9 s
Combined Consumption
11.4 L/100 km

Dimensions & Weight

Length
4,689 mm
Width
34 mm
Height
1,399 mm
Wheelbase
2,775 mm
Track, Front
1,538 mm
Track, Rear
1,561 mm
Turning Circle
11.7 m
Curb Weight
1,693 kg
Gross Weight
2,120 kg
Cargo Capacity
427 kg
Max Roof Load
75 kg

Interior Dimensions

Head Room, Front
955 mm
Head Room, Rear
892 mm
Leg Room, Front
1,074 mm
Leg Room, Rear
851 mm
Hip Room, Front
1,374 mm
Hip Room, Rear
1,130 mm
Shoulder Room, Front
1,374 mm
Shoulder Room, Rear
1,298 mm

Chassis & Body

Body Material
Steel
Front Doors
Conventional
Door Handles
Pull-out
Mirror Type
Conventional
Window Lifts, Front
Powered
Heated Windows
Rear
Normal Roof
Yes

Brakes & Wheels

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Anti-roll Bar
Front, Rear
Tire Pressure Monitoring System
Yes
Rim Material
Aluminium
Rim Type
Disc Wheel

Lighting

Main Beam
Xenon
Daytime Running Light
LED
Fog Lights
Yes

Fuel & Engine Details

Tank Volume
62.5 l
Compression Ratio
10.2 :1

Suspension & Exterior

Cooling
Ventilated
Independent
Multi-link
Spring, Rear
Coil
Independent
Multi-link
Adjustments
Electrical
Folding
Electrical
Heated
Yes
Special Features
Headlight Washers

Instruments & Infotainment

Trip Computer
Yes
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Outside Temperature Indicator
Yes
Radio
AM, DAB+, FM
Bluetooth
Audio, Phone
Center Display
8"
Center Display Controls
Touchscreen
Total Number of Speakers
12 pcs
Speaker Brand
Bose
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard

Interior & Controls

Cup Holders
Yes
Read Light
Front, Rear
Guide Light
Bottom of the Doors, Footwell (Front)
Ambient Light
Yes
Make-up Mirror
Driver Side, Passenger Side
Clock
Digital
12V Outlet
Yes
Carpets
Front, Rear
Multifunction Steering Wheel
Yes
Cruise Control
Yes
Heated
Optional
Power Steering
Yes
Adjustments
User Memory
Material
Leather
Colour
Black
Rear Trunk
Yes
Volume
295 l
Hatch Opening Type
Under Rear Window
Pedals
Aluminium, Sport

Seats

Power Seat, Driver
Yes
Heated Seats
Driver, Passenger
Armrest
Yes
Type of Seat
Sport Seats
Collapsible
Manual
Type of Seat
Adult

Convenience & Equipment

Keyless Entry
Yes
Keyless Start
Yes
Cruise Control
Yes
Cameras
Rear
Wireless Phone Charger
Yes
GPS
Navigation
Tire Repair Kit
Yes

Safety & Driver Assistance

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Optional
Lane Assist System
Yes
Sign Assist
Optional
City
16.9 l/100km
Anti-lock Braking System (ABS)
Yes
Differential Lock
Electronic, Limited Slip Differential (LSD)
Parking Sensors
Front, Rear
Blind Spot Detection (BLIS)
Optional
Rain Sensors
Optional
Immobiliser
Yes

Security

Anti-theft Alarm
Yes
Central Locking
Remote

Airbags & Restraints

Frontal Airbag
Driver: Yes, Passenger: Yes, Rear: -
Side Chest Airbag
Driver: Yes, Passenger: Yes, Rear: -
Knee Airbag
Driver: Yes, Passenger: -, Rear: -
Curtain Airbag
Driver: Yes, Passenger: Yes, Rear: Yes

Quick Facts

Fuel Type
Gasoline
Country
United States

Appearances

Top Gear

TV Show

Jay Leno's Garage

TV Show

Gran Turismo 7

Video Game

Forza Motorsport

Video Game

Generation

1st Generation Facelift (2015-2019)
