2016 Jaguar F-Pace 20d AWD
- Diesel
- United Kingdom
Photos
Specifications
Vehicle Details
- Year
- 2016
- Make
- Jaguar
- Model
- F-Pace
- Variation
- 20d AWD
- Generation
- X761 (2017-2021)
- Seats
- 5
- Doors
- 5
- Fuel
- Diesel
- Drivetrain
- AWD
Powertrain
- Engine Name
- 2.0 I4
- Engine Configuration
- Inline
- Power (hp)
- 180 hp
- Power (kW)
- 132 kW
- Brake Horsepower
- 177 bhp
- Torque (Nm)
- 430 Nm
- Torque (lb-ft)
- 317 lb-ft
- RPM at Max Power
- 4,000 rpm
- RPM at Max Torque
- 1,750 rpm
- Displacement (cc)
- 1,999 cc
- Displacement (litres)
- 2.0 l
- Cylinders
- 4
- Valves Per Cylinder
- 4
- Bore
- 83 mm
- Stroke
- 92.4 mm
Performance & Efficiency
- Top Speed (km/h)
- 208 km/h
- Top Speed (mph)
- 129 mph
- Acceleration, 0-60 mph
- 8 s
- Acceleration, 0-100 km/h
- 8.7 s
- Combined Consumption
- 5.2 - 5.3 L/100 km
Dimensions & Weight
- Length
- 4,731 mm
- Width
- 30 mm
- Width With Mirrors
- 2,175 mm
- Height
- 1,651 mm
- Wheelbase
- 2,874 mm
- Track, Front
- 1,641 mm
- Track, Rear
- 1,645 mm
- Ground Clearance
- 213 mm
- Turning Circle
- 11.59 m
- Curb Weight
- 1,767 - 1,775 kg
- Gross Weight
- 2,460 kg
- Cargo Capacity
- 685 - 693 kg
- Max Roof Load
- 75 kg
Interior Dimensions
- Head Room, Front
- 1,007 mm
- Head Room, Rear
- 977 mm
- Leg Room, Front
- 1,024 mm
- Leg Room, Rear
- 945 mm
- Shoulder Room, Front
- 1,465 mm
- Shoulder Room, Rear
- 1,417 mm
Chassis & Body
- Front Doors
- Conventional
- Mirror Type
- Conventional
- Window Lifts, Front
- Powered
- Heated Windows
- Rear
- Heat-Insulating Windows
- First Row, Front, Rear, Second Row
- Antenna
- Shark Fin
Brakes & Wheels
- Front Brakes
- Disc Brakes
- Rear Brakes
- Disc Brakes
- Tire Pressure Monitoring System
- Yes
- Number of Bolts
- 5
- Bolt Distance
- 108
- Nut/Bolt Dimensions
- M14x1.5
- Central Bore, Front
- 63.4
- Fastening Type
- Lug Nuts
- Tightening Torque
- 133 Nm
- Rim Material
- Alloy
- Rim Type
- Disc Wheel
Lighting
- Rear Lights
- LED
- Fog Lights
- Optional
Fuel & Engine Details
- Tank Volume
- 60 l
- Compression Ratio
- 15.5 :1
Suspension & Exterior
- Cooling
- Ventilated
- Adjustments
- Electrical
- Heated
- Yes
- Turning Signal
- Yes
- Rear
- Yes
- Special Features
- Come Home/Leaving Lights, Headlight Range Adjustment, Headlight Washers
Instruments & Infotainment
- Trip Computer
- Yes
- Fuel Gauge
- Digital
- Climate Control
- Automatic
- Air Condition
- Yes
- Radio
- AM, FM, HD Radio
- App-Connect
- Optional
- Bluetooth
- Audio, Phone
- Center Display
- 8 - 8 – 12.3"
- Center Display Controls
- Touchscreen
- Total Number of Speakers
- 6 - 11 – 17 pcs
- Adjustments
- Telescope, Tilt
Interior & Controls
- Cup Holders
- Yes
- Read Light
- Front
- Guide Light
- Yes
- Ambient Light
- Optional
- Make-up Mirror
- Driver Side, Passenger Side
- Clock
- Digital
- 12V Outlet
- Front
- Carpets
- Optional
- Multifunction Steering Wheel
- Yes
- Cruise Control
- Activate/Deactivate, Resume, Speed Up/Down
- Heated
- Optional
- Power Steering
- Electro-mechanical
- Material
- Leather
- Colour
- Black
- Steering Mechanism
- Rack and Pinion
- Rear Trunk
- Yes
- Volume
- 650 l
Seats
- Power Seat, Driver
- Optional
- Power Seat, Passenger
- Yes
- Heated Seats
- Optional
- Ventilated Seats
- Optional
- Type of Seat
- Adult
- Collapsible
- Yes
Convenience & Equipment
- Keyless Entry
- Yes
- Keyless Start
- Yes
- Cruise Control
- Yes
- Cameras
- Optional
- GPS
- Optional
Seatbelts
- Three-Point-Belt
- Centre Rear Seat
Safety & Driver Assistance
- Electronic Stability Control (ESC)
- Yes
- Safe Exit Warning (SEW)
- Optional
- Lane Assist System
- Optional
- Autonomous Emergency Brake System (AEB)
- Optional
- City
- 6 – 6.2 l/100km
- Anti-lock Braking System (ABS)
- Yes
- Electronic Brakeforce Distribution (EBD)
- Yes
- Electronic Brake Assist (BA/EBA)
- Yes
- Parking Sensors
- Rear
- Blind Spot Detection (BLIS)
- Optional
- Light Sensor
- Yes
- Rain Sensors
- Yes
- Immobiliser
- Yes
Security
- Anti-theft Alarm
- Yes
- Central Locking
- Yes
- Emergency Call
- Yes
Airbags & Restraints
- Frontal Airbag
- Driver: Yes, Passenger: Yes, Rear: -
- Side Chest Airbag
- Driver: Yes, Passenger: Yes, Rear: -
- Side Head Airbag
- Driver: Yes, Passenger: Yes, Rear: Yes
- Curtain Airbag
- Driver: Yes, Passenger: Yes, Rear: Yes
- Airbag cut-off Switch
- Driver: -, Passenger: Yes, Rear: -
- Seat Belt Reminder
- Driver: Yes, Passenger: Yes, Rear: Yes
- Belt Pretensioner
- Driver: Yes, Passenger: Yes, Rear: Yes
- Belt Load Limiter
- Driver: Yes, Passenger: Yes, Rear: Yes
Classification
- Australian Classification
- Medium SUV
- European Segment
- J-Segment JC-Segment
Quick Facts
- Fuel Type
- Diesel
- Country
- United Kingdom
Appearances
Generation
X761 (2017-2021)
