2017 Cadillac XT5 3.6 V6 AFM AWD Automatic, 8-speed
- Gasoline
- United States
Photos
Specifications
Vehicle Details
- Year
- 2017
- Make
- Cadillac
- Model
- XT5
- Variation
- 3.6 V6 AFM AWD Automatic, 8-speed
- Generation
- 1st Generation Facelift (2020-present)
- Seats
- 5
- Doors
- 5
- Fuel
- Gasoline
- Drivetrain
- AWD
Powertrain
- Engine Name
- 3.6 V6
- Engine Configuration
- V
- Power (hp)
- 314 hp
- Power (kW)
- 231 kW
- Brake Horsepower
- 310 bhp
- Torque (Nm)
- 368 Nm
- Torque (lb-ft)
- 271 lb-ft
- RPM at Max Power
- 6,600 rpm
- RPM at Max Torque
- 5,000 rpm
- Displacement (cc)
- 3,649 cc
- Displacement (litres)
- 3.6 l
- Cylinders
- 6
- Valves Per Cylinder
- 4
- Bore
- 95 mm
- Stroke
- 85.6 mm
Dimensions & Weight
- Length
- 4,813 mm
- Width
- 1,905 mm
- Height
- 1,676 mm
- Wheelbase
- 2,857 mm
- Track, Front
- 1,636 mm
- Track, Rear
- 1,636 mm
- Ground Clearance
- 200 mm
- Turning Circle
- 11.8 m
- Curb Weight
- 1,931 - 1,976 kg
Interior Dimensions
- Head Room, Front
- 1,009 mm
- Head Room, Rear
- 976 mm
- Leg Room, Front
- 1,046 mm
- Leg Room, Rear
- 1,004 mm
- Hip Room, Front
- 1,424 mm
- Hip Room, Rear
- 1,391 mm
- Shoulder Room, Front
- 1,482 mm
- Shoulder Room, Rear
- 1,429 mm
Chassis & Body
- Body Material
- Steel
- Front Doors
- Conventional
- Door Handles
- Pull-out
- Mirror Type
- Conventional
- Window Lifts, Front
- Powered
Brakes & Wheels
- Front Brakes
- Disc Brakes
- Rear Brakes
- Disc Brakes
- Anti-roll Bar
- Front, Rear
- Tire Pressure Monitoring System
- Yes
- Number of Bolts
- 6
- Bolt Distance
- 120
- Nut/Bolt Dimensions
- M14x1.5
- Central Bore, Front
- 66.9
- Fastening Type
- Lug Nuts
- Tightening Torque
- 190 Nm
Lighting
- Rear Lights
- LED
- Daytime Running Light
- LED
Fuel & Engine Details
- Tank Volume
- 82 l
- Compression Ratio
- 11.5 :1
Suspension & Exterior
- Cooling
- Ventilated
- Independent
- MacPherson Strut
- Spring, Rear
- Coil
- Independent
- Multi-link
- Adjustments
- Electrical
- Heated
- Yes
Instruments & Infotainment
- Trip Computer
- Yes
- Climate Control
- Automatic
- Radio
- AM, FM
- App-Connect
- Android Auto, Apple CarPlay
- Bluetooth
- Phone
- Center Display
- 8"
- Center Display Controls
- Touchscreen
- Total Number of Speakers
- 8 pcs
- Speaker Brand
- Bose
Interior & Controls
- Cup Holders
- Yes
- Multifunction Steering Wheel
- Yes
- Cruise Control
- Yes
- Heated
- Optional
- Power Steering
- Yes
- Material
- Leather
- Rear Trunk
- Yes
- Volume
- Yes
- Hatch Opening Type
- From Roof
Seats
- Power Seat, Driver
- Optional
- Armrest
- Yes
- Collapsible
- Yes
Convenience & Equipment
- Keyless Entry
- Yes
- Cruise Control
- Yes
- Cameras
- Rear
Safety & Driver Assistance
- Electronic Stability Control (ESC)
- Yes
- Lane Assist System
- Optional
- City
- 18 MPG
- Anti-lock Braking System (ABS)
- Yes
- Electronic Brake Assist (BA/EBA)
- Yes
- Parking Sensors
- Rear
- Blind Spot Detection (BLIS)
- Optional
Security
- Anti-theft Alarm
- Optional
- Central Locking
- Yes
Airbags & Restraints
- Frontal Airbag
- Driver: Yes, Passenger: Yes, Rear: -
- Knee Airbag
- Driver: Yes, Passenger: -, Rear: -
- Curtain Airbag
- Driver: Yes, Passenger: Yes, Rear: Yes
Classification
- Australian Classification
- Medium SUV
- European Segment
- J-Segment JC-Segment
Quick Facts
- Fuel Type
- Gasoline
- Country
- United States
Appearances
Generation
1st Generation Facelift (2020-present)
