2022 Mazda CX-60 PHEV
- Plug-in Hybrid Gasoline
- Japan
Photos
Specifications
Vehicle Details
- Year
- 2022
- Make
- Mazda
- Model
- CX-60
- Variation
- PHEV
- Generation
- 1st Generation (2022-2025)
- Seats
- 5
- Doors
- 5
- Fuel
- Plug-in Hybrid Gasoline
- Drivetrain
- AWD
Powertrain
- Engine Name
- 2.5 17.80 kWh I4
- Engine Configuration
- Inline
- Power (hp)
- 327 hp
- Power (kW)
- 241 kW
- Brake Horsepower
- 323 bhp
- Torque (Nm)
- 500 Nm
- Torque (lb-ft)
- 369 lb-ft
- RPM at Max Power
- 6,000 rpm
- RPM at Max Torque
- 1,500 rpm
- Displacement (cc)
- 2,488 cc
- Displacement (litres)
- 2.5 l
- Cylinders
- 4
- Valves Per Cylinder
- 4
- Bore
- 89 mm
- Stroke
- 100 mm
Performance & Efficiency
- Top Speed (km/h)
- 200 km/h
- Top Speed (mph)
- 124 mph
- Acceleration, 0-100 km/h
- 5.8 s
- Combined Consumption
- 23 L/100 km
Dimensions & Weight
- Length
- 4,745 mm
- Width
- 1,890 mm
- Width With Mirrors
- 2,134 mm
- Height
- 817 mm
- Wheelbase
- 2,870 mm
- Track, Front
- 1,640 mm
- Track, Rear
- 1,645 mm
- Ground Clearance
- 170 - 175 mm
- Turning Circle
- 10.8 m
- Curb Weight
- 2,055 - 2,147 kg
- Gross Weight
- 2,667 kg
- Cargo Capacity
- 612 kg
- Max Roof Load
- 75 kg
Interior Dimensions
- Head Room, Front
- 1,004 mm
- Head Room, Rear
- 984 mm
- Leg Room, Front
- 1,058 mm
- Leg Room, Rear
- 990 mm
- Shoulder Room, Front
- 1,504 mm
- Shoulder Room, Rear
- 1,441 mm
Chassis & Body
- Front Doors
- Conventional
- Door Handles
- Pull-up
- Mirror Type
- Conventional
- Window Lifts, Front
- Powered
- Heated Windows
- Rear
- Heat-Insulating Windows
- First Row, Front, Rear, Second Row
- Antenna
- Yes
Brakes & Wheels
- Front Brakes
- Disc Brakes
- Rear Brakes
- Disc Brakes
- Tire Pressure Monitoring System
- Direct
- Number of Bolts
- 5
- Bolt Distance
- 114.3
- Nut/Bolt Dimensions
- M12x1.5
- Central Bore, Front
- 67.1
- Central Bore, Rear
- 67.1
- Fastening Type
- Lug Nuts
- Tightening Torque
- 108 Nm
- Rim Material
- Alloy
- Rim Type
- Disc Wheel
Lighting
- Low Beam
- LED
- Main Beam
- LED
- Rear Lights
- LED
- Daytime Running Light
- LED
- Fog Lights
- Yes
Fuel & Engine Details
- Tank Volume
- 50 l
- Compression Ratio
- 13 :1
Electric
- Electric Vehicle Type
- Plug-in Hybrid
- Battery Capacity
- 17.8 kWh
- Electric Range (km)
- 65 km
- Electric Range (mi)
- 39 mi
Suspension & Exterior
- Cooling
- Ventilated
- Independent
- Double Wishbone
- Independent
- Multi-link
- Adjustments
- Electrical
- Folding
- Electrical (Automatic Parking Fold)
- Heated
- Yes
- Turning Signal
- Yes
- Intermittent Control
- Yes
- Rear
- LED
- Special Features
- Adaptive Headlights, Automatic Headlight Activation, Come Home/Leaving Lights, Headlight Washers, Main Beam Assist
- Headlight Range Adjustment
- Automatic (Dynamic)
Instruments & Infotainment
- Trip Computer
- Yes
- Speedometer
- Digital
- Tachometer
- Digital
- Fuel Gauge
- Digital
- Coolant Temperature
- Digital
- Climate Control
- Automatic
- Number of Climate Zones
- 2
- Air Condition
- Yes
- Pollen Filter
- Yes
- Outside Temperature Indicator
- Yes
- Controls
- Buttons
- Radio
- AM, DAB+, FM
- App-Connect
- Android Auto, Apple CarPlay (Wired | Wireless)
- Bluetooth
- Audio, Phone
- Center Display
- Yes
- Center Display Controls
- Buttons, Rotary Dial, Touchscreen
- Total Number of Speakers
- 8 - 12 pcs
- Adjustments
- Mechanical
- Rear-view Mirror: Mirror Type
- Standard
Interior & Controls
- Cup Holders
- Yes
- Read Light
- Front
- Guide Light
- Entry Guard
- Ambient Light
- Optional
- Make-up Mirror
- Driver Side, Passenger Side
- Clock
- Yes
- Carpets
- Optional
- Multifunction Steering Wheel
- Yes
- Menu Navigation
- Yes
- Cruise Control
- Activate/Deactivate, Resume, Speed Up/Down (Buttons)
- Heated
- Yes
- Power Steering
- Electric
- Number of Spokes
- 3
- Material
- Leather
- Steering Mechanism
- Rack and Pinion
- Rear Trunk
- Yes
- Volume
- 570 l
- Hatch Opening Type
- From Roof
- Transmission Knob Material
- Leather
- Pedals
- Standard
Seats
- Power Seat, Driver
- Optional
- Power Seat, Passenger
- Optional
- Heated Seats
- Optional
- Armrest
- Middle
- Ventilated Seats
- Optional
- Type of Seat
- Adult
- Collapsible
- Manual
Convenience & Equipment
- Keyless Entry
- Optional
- Cruise Control
- Yes
- Cameras
- Optional
- GPS
- Navigation
- Driving Mode Selection
- Normal, Sport
- Horn
- Dual Note
- Tire Repair Kit
- Yes
- Compressor
- Yes
Seatbelts
- Height Adjustable Retractor
- Yes
- Manual
- Yes
- Three-Point-Belt
- Centre Rear Seat, Front Seats, Outer Rear Seats
Safety & Driver Assistance
- Electronic Stability Control (ESC)
- Yes
- Front Cross-Traffic Alert (FCTA)
- Yes
- Safe Exit Warning (SEW)
- Yes
- Lane Assist System
- Yes
- Lane Departure Warning (LDW)
- Yes
- Lane Keeping Assist (LKA)
- Yes
- Sign Assist
- Yes
- Autonomous Emergency Brake System (AEB)
- Yes
- Car-to-car
- Yes
- Anti-lock Braking System (ABS)
- Four-channel
- Electronic Brakeforce Distribution (EBD)
- Yes
- Electronic Brake Assist (BA/EBA)
- Yes
- Parking Sensors
- Front, Rear
- Blind Spot Detection (BLIS)
- Yes
- Light Sensor
- Yes
- Rain Sensors
- Yes
- Immobiliser
- Yes
- Electronic
- Yes
Security
- Anti-theft Alarm
- Optional
- Central Locking
- Remote
- Emergency Call
- Yes
Airbags & Restraints
- Frontal Airbag
- Driver: Yes, Passenger: Yes, Rear: -
- Side Chest Airbag
- Driver: Yes, Passenger: Yes, Rear: Yes
- Side Head Airbag
- Driver: Yes, Passenger: Yes, Rear: Yes
- Knee Airbag
- Driver: Yes, Passenger: -, Rear: -
- Curtain Airbag
- Driver: Yes, Passenger: Yes, Rear: Yes
- Airbag cut-off Switch
- Driver: -, Passenger: Yes, Rear: -
- Seat Belt Reminder
- Driver: Yes, Passenger: Yes, Rear: Yes
- Belt Pretensioner
- Driver: Yes, Passenger: Yes, Rear: Yes
- Belt Load Limiter
- Driver: Yes, Passenger: Yes, Rear: Yes
Classification
- Australian Classification
- Large SUV
- European Segment
- J-Segment JC-Segment, JD-Segment
Quick Facts
- Fuel Type
- Plug-in Hybrid Gasoline
- Country
- Japan
Appearances
Generation
1st Generation (2022-2025)
