2024 Hyundai Santa Fe HEV Automatic, 6-speed
- Hybrid Gasoline
- South Korea
Photos
Specifications
Vehicle Details
- Year
- 2024
- Make
- Hyundai
- Model
- Santa Fe
- Variation
- HEV Automatic, 6-speed
- Generation
- CM (2006-2010)
- Seats
- 5
- Doors
- 5
- Fuel
- Hybrid Gasoline
- Drivetrain
- 2WD
Powertrain
- Engine Name
- 1.6
- Engine Configuration
- Inline
- Power (hp)
- 235 hp
- Power (kW)
- 173 kW
- Brake Horsepower
- 232 bhp
- Torque (Nm)
- 264 Nm
- Torque (lb-ft)
- 195 lb-ft
- RPM at Max Power
- 5,500 rpm
- RPM at Max Torque
- 1,500 rpm
- Displacement (cc)
- 1,598 cc
- Displacement (litres)
- 1.6 l
Performance & Efficiency
- Top Speed (km/h)
- 190 km/h
- Top Speed (mph)
- 118 mph
- Acceleration, 0-100 km/h
- 9.5 s
Dimensions & Weight
- Length
- 4,830 mm
- Width
- 1,900 mm
- Height
- 1,720 - 1,780 mm
- Wheelbase
- 2,815 mm
- Track, Front
- 1,637 - 1,646 mm
- Track, Rear
- 1,647 - 1,656 mm
- Ground Clearance
- 177 mm
- Turning Circle
- 11.6 m
- Curb Weight
- 2,225 kg
- Max Roof Load
- 100 kg
Interior Dimensions
- Head Room, Front
- 1,020 - 1,045 mm
- Head Room, Rear
- 1,007 - 1,030 mm
- Leg Room, Front
- 1,052 mm
- Leg Room, Rear
- 1,075 mm
- Shoulder Room, Front
- 1,511 mm
- Shoulder Room, Rear
- 1,475 mm
Chassis & Body
- Front Doors
- Conventional
- Door Handles
- Same as Car
- Mirror Type
- Conventional
- Window Lifts, Front
- Powered
- Heated Windows
- Rear
- Heat-Insulating Windows
- First Row, Front, Rear, Second Row
- Antenna
- Shark Fin
Brakes & Wheels
- Front Brakes
- Disc Brakes
- Rear Brakes
- Disc Brakes
- Tire Pressure Monitoring System
- Direct
- Number of Bolts
- 5
- Bolt Distance
- 114.3
- Nut/Bolt Dimensions
- M12x1.5
- Central Bore, Front
- 67.1
- Central Bore, Rear
- 67.1
- Fastening Type
- Lug Nuts
- Tightening Torque
- 107 Nm
- Rim Material
- Alloy
- Rim Type
- Disc Wheel
Lighting
- Low Beam
- LED
- Main Beam
- LED
- Rear Lights
- LED
- Daytime Running Light
- LED
- Fog Lights
- Yes
Fuel & Engine Details
- Tank Volume
- 67 l
Electric
- Electric Vehicle Type
- Hybrid
Suspension & Exterior
- Cooling
- Ventilated
- Independent
- MacPherson Strut
- Spring, Rear
- Coil
- Independent
- Multi-link
- Adjustments
- Electrical
- Folding
- Electrical
- Heated
- Yes
- Turning Signal
- Yes
- Intermittent Control
- Yes
- Number of Windscreen Wipers, Front
- 2
- Rear
- LED
- Special Features
- Automatic Headlight Activation, Headlight Range Adjustment
Instruments & Infotainment
- Trip Computer
- Yes
- Speedometer
- Digital
- Tachometer
- Digital
- Fuel Gauge
- Digital
- Coolant Temperature
- Digital
- Climate Control
- Automatic
- Number of Climate Zones
- 2
- Air Condition
- Yes
- Pollen Filter
- Yes
- Outside Temperature Indicator
- Yes
- Controls
- Rotary Dials, Touchscreen
- Radio
- AM, DAB+, FM, RDS
- App-Connect
- Android Auto, Apple CarPlay
- Bluetooth
- Audio, Phone
- Center Display
- 12.3"
- Center Display Controls
- Touchscreen
- Total Number of Speakers
- 6 - 12 pcs
- Subwoofer
- Optional
- Adjustments
- Mechanical
- Anti-glare
- Automatic
- Rear-view Mirror: Mirror Type
- Standard
Interior & Controls
- Cup Holders
- Yes
- Read Light
- Front, Rear
- Guide Light
- Entry Guard
- Ambient Light
- Optional
- Make-up Mirror
- Driver Side, Passenger Side
- Clock
- Yes
- 12V Outlet
- Front, Trunk
- Carpets
- Front, Rear
- Multifunction Steering Wheel
- Yes
- Menu Navigation
- Buttons, Scrolling Wheel
- Cruise Control
- Activate/Deactivate, Speed Up/Down (Scrolling Wheel)
- Heated
- Yes
- Power Steering
- Electric
- Adjustments
- Seat Depth
- Number of Spokes
- 3
- Material
- Leather
- Colour
- Black
- Steering Mechanism
- Rack and Pinion
- Rear Trunk
- Yes
- Volume
- 725 l
- Hatch Opening Type
- From Roof
Seats
- Power Seat, Driver
- Optional
- Power Seat, Passenger
- Optional
- Heated Seats
- Driver, Passenger
- Armrest
- Middle
- Ventilated Seats
- Optional
- Type of Seat
- Adult
- Collapsible
- Manual
Convenience & Equipment
- Keyless Entry
- Yes
- Keyless Start
- Yes
- Cruise Control
- Yes
- Cameras
- Rear
- View Location
- Center Display
- Voice Control
- Media, Phone
- Wireless Phone Charger
- Front
- GPS
- Navigation
- Driving Mode Selection
- Normal
- Horn
- Dual Note
- Tire Repair Kit
- Yes
- Compressor
- Optional
- Fire Extinguisher
- Optional
- Warning Triangle
- Optional
- First Aid Kit
- Optional
Seatbelts
- Height Adjustable Retractor
- Yes
- Manual
- Yes
- Three-Point-Belt
- Centre Rear Seat, Front Seats, Outer Rear Seats
Safety & Driver Assistance
- Electronic Stability Control (ESC)
- Yes
- Forward Collision Warning (FCW)
- Yes
- Rear Cross-Traffic Alert (RCTA)
- Optional
- Lane Assist System
- Yes
- Lane Departure Warning (LDW)
- Yes
- Lane Keeping Assist (LKA)
- Yes
- Autonomous Emergency Brake System (AEB)
- Yes
- Car-to-car
- Yes
- City
- Yes
- Anti-lock Braking System (ABS)
- Four-channel
- Electronic Brakeforce Distribution (EBD)
- Yes
- Electronic Brake Assist (BA/EBA)
- Yes
- Parking Sensors
- Front, Rear
- Blind Spot Detection (BLIS)
- Optional
- Light Sensor
- Yes
- Rain Sensors
- Yes
- Immobiliser
- Yes
- Electronic
- Yes
Security
- Anti-theft Alarm
- Yes
- Central Locking
- Auto Lock (Speed Sensitive), Remote
- Emergency Call
- Yes
Airbags & Restraints
- Frontal Airbag
- Driver: Yes, Passenger: Yes, Rear: -
- Side Chest Airbag
- Driver: Yes, Passenger: Yes, Rear: Yes
- Side Head Airbag
- Driver: Yes, Passenger: Yes, Rear: Yes
- Knee Airbag
- Driver: Yes, Passenger: -, Rear: -
- Curtain Airbag
- Driver: Yes, Passenger: Yes, Rear: Yes
- Airbag cut-off Switch
- Driver: -, Passenger: Yes, Rear: -
- Seat Belt Reminder
- Driver: Yes, Passenger: Yes, Rear: Yes
- Belt Pretensioner
- Driver: Yes, Passenger: Yes, Rear: Yes
- Belt Load Limiter
- Driver: Yes, Passenger: Yes, Rear: Yes
Classification
- Australian Classification
- Large SUV
- European Segment
- J-Segment JD-Segment
Quick Facts
- Fuel Type
- Hybrid Gasoline
- Country
- South Korea
